Volt Edge 25 Gallon ATV 7

  • Item #: 5303076
  • Mfg #: 20V-25-700-ATV
  • $549.99

Product Description

The Volt Edge 25 Gallon ATV 7 Nozzle Boom Sprayer represents a major step in 21st Century Lithium Ion Battery powered technology. The polyethylene, UV resistant, high density tank has a 5 inch tethered lid for easy access and is completely drainable. This model features the best in class High Flo High Performance 2.4 GPM Pump with inline fuse protection. The Lever Grip Handgun distributes up to 30 feet of horizontal spray, 16 feet of vertical spray and comes with 15 feet of 3/8 inch hose.  With a 7 Nozzle Folding Boom, this model distributes 12 feet of total spray coverage offering increased capacity with precise liquid application.  Our FIMCO exclusive manifold places pressure control and boom operation conveniently at your fingertips to fine tune your spray pattern.  A wireless remote and rechargeable Lithium Ion battery removes the need for additional lengthy wires attached to your ATV or UTV batteries.  Compact, versatile and powerful, the new Volt Edge sprayers are optimized to deliver peak efficiency.


 Product Manual


Product Features

  • 2.4 GPM High Flo High Performance Pump features an internally fan cooled motor as well as chemically resistant valves and diaphragms which increase durability ensuring longer pump life
  • Durable 25 Gallon blow molded tank features UV stabilizers and molded drain port and 5 inch lid for easy filling
  • Folding 7 nozzle welded breakaway steel boom delivers 12 feet of total spray coverage, features Teejet® tips and is spring loaded for easy deployment, use and storage
  • Lever grip handgun features an aluminum lance and a adjustable polymer nozzle that delivers 30 feet of horizontal spray and 16 feet of vertical spray. Plus 15 feet of hose gives you the length necessary to reach tight areas, around buildings and other obstacles
  • Volt Edge 20 Volt Lithium Ion sprayers provide on demand power when you need it most

Product Specs

  • Manufacturers Warranty1 yr Consumer / 90 day Commercial
  • Tank Size (Gal)25
  • Flow (GPM)2.4
  • Pressure (PSI)60
  • Spray Gun TypeLever Handgun
  • Spray PatternAdjustable Pattern Tip
  • Pump TypeHIGH FLO
  • Spray Height (ft.)16
  • Horizontal Spray Distance (ft.)30
  • Power SupplyLithium Ion Battery
  • Hose (in. x ft.)3/8 x 15
  • Boom Spray Coverage (ft.)12
  • Pump Warranty2 yr Consumer / 90 day Commercial
