FIMCO 200 Gallon Fire Trailer with 4 Roller Pump and Fire Nozzle

  • Item #: 5303634
  • Mfg #: FT-200-4R
  • $5,299.99

Product Description

The FIMCO 200 Gallon Fire Trailer Sprayer with 4 Roller Pump and Fire Nozzle is designed to suppress fires, control dust and other water transfer applications by delivering superior liquid application in a truly universal platform. The UV resistant, molded polymer tank has a 16 inch lid for easy access and is completely drainable. Built in step allows easy filling of the 200 gallon tank. This model features a 127cc Briggs & Stratton 3.5 HP Gas Engine with a Hypro 4 Roller Pump with a 7.2 GPM max flow. The 3/4" fire hose style adjustable nozzle can soak fires from a distance by distributing up to 38 feet of horizontal spray, 27 feet of vertical spray with 100 feet of ½ inch hose with a hand rewind hose reel. This Trailer Sprayer is built on a welded powder coated steel frame with 23” x 10.5” 4 ply tires to easily pull around rough terrain, trees, brush or other obstacles. Designed to be pulled behind an ATV, UTV or tractor trailer the lightweight frame and poly tank allow easy hook up and go with a heavy duty clevis hitch. The high performance tow behind trailer sprayer is a must have for managing a control burn, extinguishing a small fire before it gets out of control or any fire emergency plan.


 Product Manual


Product Features

  • 100 Feet of 1/2" 600 PSI PVC hose with hose reel gives you the length necessary to reach tight areas, around buildings and other obstacles.
  • 23” x 1050-12, 4-Ply Tires, 10 MPH Maximum Speed
  • Banjo 3/4” Garden Hose Spray Nozzle
  • Cast iron 4 roller pump provides up to 7.2 GPM
  • Durable powder coated steel frame

Product Specs

  • Manufacturers Warranty1 yr Consumer / 90 day Commercial
  • Tank Size (Gal)200
  • Flow (GPM)6
  • Pressure (PSI)150
  • Spray Wand TypeBanjo 3/4" Spray Nozzle
  • Spray PatternAdjustable Pattern Tip
  • Pump TypeHypro 4 Roller Pump
  • Spray Height (ft.)27
  • Horizontal Spray Distance (ft.)38
  • Power SupplyGas
  • Hose (in. x ft.)1/2 x 100
  • Tire Size23 x 1050-12
  • Assembled L x W x H (in.)85 x 62 x 55
  • Pump Warranty2 yr Consumer / 90 day Commercial
